| Product Attribute | Attribute Value |
|---|---|
| Part Number | IPB60R600CP |
| Manufacturer | Cypress Semiconductor (Infineon Technologies) |
| Vgs(th) (Max) @ Id | 3.5V @ 220µA |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | PG-TO263-3-2 |
| Series | CoolMOS™ |
| Rds On (Max) @ Id, Vgs | 600mOhm @ 3.3A, 10V |
| Power Dissipation (Max) | 60W (Tc) |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Package | Bulk |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Input Capacitance (Ciss) (Max) @ Vds | 550 pF @ 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 27 nC @ 10 V |
| FET Type | N-Channel |
| FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Drain to Source Voltage (Vdss) | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 6.1A (Tc) |
